Flat Head Hexagon Riveted Nuts

Main Features

  • Main Parameters
  • FAQ

<

Thread specifications
D
M6M8M10M10M12M12
PPitch11.251.511.751.5
SNominal91113131515
Max8.9710.9712.9712.9714.9714.97
Min8.910.912.912.914.914.9
d₁Min=Nominal(H12)81011.511.513.513.5
Max8.1510.1511.6811.6813.6813.68
dkMax121416161818
k1.51.51.81.81.81.8
F0.20.30.30.30.30.3
d₀Min=Nominal91113131515
Max9.1511.1513.1513.1515.1515.15
h₁Reference1112.3151517.517.5
