Restructuring(Drawing&Annealing):

The high strength of the product comes from the subsequent heat treatment. In order to ensure the hardenability, uniformity and stability of heat treatment, VANKU takes the processing process of high-quality alloy steel as an example. The material needs to go through the following process to be used in the subsequent cold forming process.

2.1 Picking and Check the Wire Quality

2.2 Annealing

2.3 Pickling phosphorus saponification

2.4 Drawing

2.5 Spheroidizing Annealing

2.5.1 Annealing process according to established process：

The operation of furnace installation, capping and pipeline dredging shall be carried out in strict accordance with the equipment operation instructions ；

Temperature, oxygen potential, methanol flow and other process parameters were monitored and recorded in real time；

2.5.2 Test ：

Hardness :Must meet the process requirements and enterprise standards .

Decarburization ：Decarbonization is not allowed .

Spheroidizing Grade :Up to Grade 4-6

2.6 Pickling phosphorus saponification

2.6.1 Process :Low concentration pickling to remove rust and impurities -High concentration pickling depth of oxidation -Water to remove the acid -Overflow -Remove the acid again -Overflow -Phosphating rust-proof lubrication -Water to remove the acid -Overflow -Water to remove the acid -Overflow -Saponification lubrication -Finished

2.6.2 Key points of pickling control ：

HCl Concentration ,

Fe2+ Concentration ,

Pickling time Control.

2.6.3 Key points of Water Control ：

PH Level,

Real Time Monitoring ,

Ensure the Overflow ,

High pressure water gun inside and outside spray .

2.6.4 Key points of phosphating control ：

Total acidity ,

HCI ratio(Total acid /Free acid),

Real Time Monitoring,

Phosphating temperature.

2.6.5 Key points of saponification：

Grease composition,

Determination of free acidity,

Real Time Monitoring ,

Saponification temperature.

2.6.6 Precision Drawing :

Strictly control the drawing speed ,

Confirm Diameter tolerance levels comply with the requirements

2.6.7 Packing:

Key points of Packing：

Sealed packing prevents exposed to air .

2.6.8 Storage:

Different materials are divided into regions ,

Drawing quality according to validity period.
