2 Hole Lifting Anchor

Main Features

  • Main Parameters
  • FAQ

Two Hole Anchor the Full safe working load can be achieved in a thin slab or when there islow concrete strength by using a tension bar in the second hole.Longer anchors with additional holes can be produced on request. Spread anchor is a responsible transport anchor system.the anchor will be delivered prefinished and can be used for installation in all concrete components.Before using the spread anchor the environment has to be checked which is specified in the installation instruction.the two hole anchor is technically equal to spread anchor.but the two hole anchor has to complete with reinforcement as installation instruction.

2 Hole Lifting Anchor(图1)

2 Hole Lifting Anchor(图2)
